  • What is EnSuite-View?

    EnSuite-View is designed to provide organizations with innovative tools that can significantly increase their engineering productivity by leveraging CAD data, without any cost.

  • What platform(s) are EnSuite-View products supported on?

    EnSuite-View products are supported on Windows 7 & 8 (32 and 64 bit). Products are not supported on Mac platform.

  • How do I report an error message?

    Email the error message to support@cadcam-e.com.

  • What is your email privacy policy?

    We will never rent, sell or share your personal information with third parties without your permission. Information submitted to us for downloading/usage purposes is only available to CCE employees managing this service. If you've received an unsolicited or unwanted email sent via this system, please forward the email with your comments to labs@cadcam-e.com for review.

  • How do I contact sales for product upgrade?

    Please email sales at sales@cadcam-e.com for a product upgrade quote.

  • Is EnSuite-View CAD independent?

    Yes. EnSuite-View is CAD independent and does not require a license of any CAD system to operate.

  • Can you view 2D data in EnSuite-View?

    No. EnSuite-View only supports 3D data.

  • How do I report an error message?

    Email the error message to support@cadcam-e.com.

  • How do you license your products?
    CCE licenses its products on an annual subscription basis. Under this purchase model, product will work only during the period of subscription. Subscription will have to be renewed every year, for the product to operate. An Active internet connection is mandatory for subscription licensing. There is NO maintenance fee for the subscription model. The user will be eligible for all product upgrades and technical support during the
  • How do I find the product cost?
    Please email sales at sales@cadcam-e.com for a product quote.
  • What is the password for downloading software?
    Passwords are only provided to users on active subscriptions. To download free versions of our software please visit CCE Labs page.

EnSuite

  • Does EnSuite support all CAD formats?
    Cat4 : Read & Write Modules for reading & writing CATIA V4 files.
    Cat5: : Read & Write Modules for reading & writing CATIA V5 files.
    Cat6 : Read Module for reading 3dxml files.
    NX : Read & Write Modules for reading & writing NX files.
    SW : Read & Write Modules for reading & writing SOLIDWORKS files.
    SE : Read Module for reading Solid Edge files.
    Inv : Read Module for reading Autodesk Inventor files.
    PS : Read & Write Modules for reading & writing Parasolid files.
    IGES : Read & Write Modules for reading & writing IGES files.
    STEP : Read & Write Modules for reading & writing STEP files.
    3D PDF : Write Module for writing 3D PDF files.
    VDA : Read Module for reading VDA files.
    STL : Read Module for reading STL files.
    ACIS : Read Module for reading ACIS files.
  • Will EnSuite translate CAD data with a fully editable history tree?

    EnSuite translates solids as B-rep. Although we translate the assembly tree (product structure), the feature tree is not translated. As a result, users do not have the ability to pick a feature and do a right click, Edit to modify the parameters. They can however create/add new features (like fillet, chamfer etc...) to the translated B-rep model

  • Do you have a product to translate NX/Unigraphics prt files to SOLIDWORKS?

    Yes. EnSuite will translate Unigraphics files to SOLIDWORKS.

  • Do you have a product to translate CATIA V4 files to JT XT BREP 9.5?

    Yes. EnSuite will translate CATIA files to JT.

  • Do you have a translator to convert SOLIDWORKS files to Parasolid?

    Yes. EnSuite will translate SOLIDWORKS files to Parasolid.

EnSuite-Lite

  • Does EnSuite-Lite support all CAD formats?
    Cat4 : Read CATIA V4 files.
    Cat5 : Read CATIA V5 files.
    Cat6 : Read 3dxml files.
    NX : Read NX files.
    SW : Read SOLIDWORKS files.
    SE : Read Edge files.
    Inv : Read Autodesk Inventor files.
    PS : Read & Write Parasolid files.
    IGES : Read & Write IGES files.
    STEP : Read & Write STEP files.
    Pro : Read Pro/ENGINEER files.
    3D PDF : Write 3D PDF files.
    VDA : Read VDA files.
    STL : Read STL files.
    Rhino : Read Rhino files.
    JT : Read JT files.
    ACIS : Read ACIS files.
    CGR :Read CGR files.
    DWF : Read DWF files.
    SketchUp : Read SketchUp files.
  • Is Ensuite-Lite CAD independent?

    Yes. EnSuite-Lite is CAD independent and does not require a license of any CAD system to operate.

  • Can you translate 2D data with EnSuite-Lite?

    No. EnSuite-Lite only supports 3D data.

  • Will EnSuite-Lite translate CATIA files to STEP or IGES format?

    Yes.

CAT5Works

  • Is CAT5Works product CAD dependent?

    Yes. CAT5Works is a Bi-directional SOLIDWORKS/CATIA data translator, which allows file translation from within SOLIDWORKS and has the same look and feel as SOLIDWORKS. CAT5Works is compatible with SOLIDWORKS 2012 / 2013 / 2014 and requires a license of SolidWorks to operate.

  • In CAT5Works why do I get "Unable to detect a compatible SolidWorks version" dialog?

    Error message will be displayed when you try to install CAT5Works with SOLIDWORKS version below 2012 or when SolidWorks software is not installed.

  • Will CAT5Works translate CATIA data into SOLIDWORKS with a fully editable history tree

    CAT5Works translates solids as B-rep. Although we translate the assembly tree (product structure), the feature tree is not translated. As a result, users do not have the ability to pick a feature and do a right click, Edit to modify the parameters. They can however create/add new features (like fillet, chamfer etc...) to the translated B-rep model.

  • What version of CATIA V5 does the CAT5Works product translates SOLIDWORKS files to?

    Translated CATIA files can be read by CATIA V5 release 10 and above.

ConfigLink

  • How do I purchase ConfigLink?

    ConfigLink requires customization based on customer requirements. Please email sales at sales@cadcam-e.com with details of your requirements and we will get back with you within 24 hours.
